Precision curve drive system
A precision-machined tapered roller system with a PVC-lagged tapered drive roller delivers uniform belt traction from inner to outer radius.
3 m/s Max belt speed
Click the image to zoom
Conveyor Modules · Curve platform
TYPE 9074
Curve Conveyor
Smooth directional changes at speed, with the flow held through the bend.
The Curve Conveyor Type 9074 is a next-generation curved conveying module developed for high-performance parcel sorting systems that require smooth directional changes, minimal noise and outstanding reliability. Built on more than 30 years of engineering expertise, it combines advanced belt-guidance technology, a precision-machined tapered roller system and a highly modular aluminium frame. Having a speed maximum speed of 3m/s and a transport load of 50kg/m, this Power Curve is suitable for the most demanding applications.
3 m/s
max belt speed
5 angles
30° – 120°
30 min
Belt substitution
1,550 mm and
1.750 mm
1.750 mm
Centreline radius
≤70 dBA
Noise level
50 kg/m
Transport load
Key differentiator
A precision-machined tapered roller system with a PVC-lagged drive roller gives uniform belt traction right across the curve — so items hold their spacing and orientation through the bend at up to 3 m/s.
Precision curve drive
Uniform traction, right across the bend
A precision-machined tapered roller system works with advanced belt-guidance technology and a PVC-lagged tapered drive roller to deliver uniform belt traction from the inner to the outer radius. Five standard angles — 30°, 45°, 60°, 90° and 120° — on a 1,550 mm centreline radius, in working widths of 900, 1,050 and 1,500 mm, let the curve follow the layout instead of dictating it.
- 1,550 and 1,750 mmCentreline radius (mm)
- 30° – 120°Available angles
- 900 – 1,500Working widths (mm)
Weld-free and quick to service
3 m/s Max belt speed, with less to maintain
A highly modular, weld-free aluminium frame carries a proprietary combi-board slider bed that keeps friction and vibration low — which is where the ≤ 70 dBA noise floor comes from. The rapid-release belt and bearing system is engineered for fast maintenance with minimal downtime, and a reduced component count keeps the spares pool small.
- 3 m/sMax belt speed
- 30 min Belt substitution
- ≤70 dBAEmpty, constant speed
Model 9074 specifications
Technical detail
| Specification | 900 mm | 1,050 mm | 1,500 mm |
|---|---|---|---|
| Available standard working width (mm) | 900 | 1,050 | 1,500 |
| Available angles | 30° · 45° · 60° · 90° · 120° | ||
| Centreline curve radius (mm) | 1,550 and 1,750 | ||
| Conveying height H (mm) | Min 300 | ||
| Side guard height h (mm) | 100 – 600 | ||
| Transport load | 50 kg/m | ||
| Belt speed | Maximum 3 m/s | ||
| Noise level (empty, constant speed) | ≤ 70 dBA | ||
| Belt material | 2-layer & antistatic (Ammeraal / Habasit); flame-retardant option available | ||
| Compliance | CE Machinery Directive · ISO/EN safety standards | ||
Transport load refers to an evenly distributed load along the conveying surface. All dimensions in millimetres unless stated. Specifications subject to change without notice.
Modular, weld-free frame design
A highly modular aluminium frame structure assembled without welds — lighter, dimensionally consistent and straightforward to reconfigure on site.
Rapid-release belt & bearing system
Belt and bearings release quickly for service, engineered for fast maintenance with minimal downtime rather than a planned line stoppage.
High-durability slider bed
A proprietary combi-board slider bed keeps friction and vibration low — the source of both the quiet running and the belt's service life.
Flexible integration & high throughput
Five standard angles and three working widths integrate into existing layouts, carrying up to 6,000 items per hour at belt speeds to 3 m/s.
Proven reliability, fewer components
Over 40 years of engineering expertise in a leaner mechanical design — fewer parts to stock and replace, compliant with CE and ISO/EN standards.
Parcel & postal sorting plants
Directional changes without losing spacing or orientation.
Logistics & distribution centres
High-capacity routing between storage, picking and dispatch.
Lines requiring curved routing
Any conveyor run that has to change direction at line speed.
Singulation, merge & feed systems
Compact installations needing smooth, high-speed curvature.
Technical datasheetPDF · on request
CAD / STEP model3D · on request
Products cataloguePDF · full range
Datasheets and CAD models are supplied on request — send us your project details and our engineers will share the documentation for your configuration.
Combine freely
Related conveyor modules
Every module shares one frame logic and drive concept — build the 9074 into a complete line.
TYPE 9008
Conveyor Modules
Belt Conveyors CHD
Straight runs linking one curve to the next, up to 11.95 m per module.
View product
TYPE 9015
Conveyor Modules
Belt Conveyors Gappex
Gap-control conveyor at a record-low 110 mm, setting spacing before sortation.
View product
TYPE 9073
Conveyor Modules
Aligner
Squares parcels to the reference edge after the bend, to 99.5% accuracy.
View product
TYPE 9083
Conveyor Modules
High Density Line Splitter
